Name: Glitherm PRO Concentrate
SKU: Gli-0016-1
Availability: InStock

CHARACTERICTICS

Heat transfer fluid concentrate allowing the preparation of a working solution with a concentration tailored to the installation requirements
Lower transportation and storage costs
Does not contain CMR substances (carcinogenic, mutagenic or toxic to reproduction)
Holds an ITB Technical Recommendation and PZH Hygienic Certificate
Provides comprehensive corrosion protection for the installation
Helps reduce the risk of deposit formation
Supports maintaining the cleanliness of the installation
Contains anti-foaming additives that reduce foaming during filling and operation
Does not contain glycerine or alcohols
Designed for multi-season use
Manufactured from virgin raw materials
5-year warranty

Base color:

Other colors available:

Available packages:

Clear

SZCZEGÓŁY

GLITHERM PRO CONCENTRATE is a highly concentrated heat transfer and antifreeze fluid designed to protect installations against freezing. The product is based on high-quality monopropylene glycol (MPG) and is intended for the preparation of working solutions with parameters tailored to the requirements of a specific installation.

GLITHERM PRO Concentrate is designed for use in heating, cooling and process installations where a working fluid based on monopropylene glycol is required. A carefully selected package of corrosion inhibitors and performance-enhancing additives provides effective corrosion protection, helps reduce the formation of deposits and supports the cleanliness of the system. High-quality raw materials protect both the fluid and installation components against degradation, ensuring long-lasting, reliable and efficient operation.
Dilution

GLITHERM PRO CONCENTRATE is not a ready-to-use product. It must be diluted with water before application. The manufacturer recommends using demineralized water to prepare working solutions.

To achieve the required level of freeze protection, prepare the mixture according to the following table:

Required minimum temperature of the mixture in °C	% Concentrate*	% Demineralized Water*
-35°C	55	45
-30°C	52	48
-25°C	47	53
-20°C	42	58
-15°C	36	64

* Volume percentage concentration.

For GLITHERM PRO Concentrate dilution ratios intended for non-standard operating temperatures not listed in the table above, please consult our Customer Service Department. Our advisors will perform the necessary calculations and provide a dedicated solution tailored to your requirements.

Applications
GLITHERM PRO fluid is suitable for use in:

Heating, central heating and technological heat recovery systems
Cooling and air-conditioning systems (HVAC)
Heat pumps, including air-source and ground-source systems
Refrigeration units and chilled water systems
Installations using renewable energy sources, including solar systems
Industrial process cooling systems
Temperature control systems used in technological and production processes
Industrial installations requiring a monopropylene glycol-based fluid
Fire protection and sprinkler systems requiring freeze protection

Material Compatibility
GLITHERM PRO fluid is compatible with installations made of the following materials:

steel
cast iron
aluminium
copper
solder
brass

Application Limitations
GLITHERM PRO fluids should not be used in installations containing galvanized components, as they may accelerate corrosion and contribute to the formation of deposits, potentially reducing system performance.

UV Leak Detection Additive
Upon customer request, the fluid can be supplemented with a UV tracer, which enables quick detection of leaks using a UV lamp. The additive does not affect the product’s performance properties.

CLP Classification and Labelling
Always refer to the information provided on the product label.

Precautionary statements:
P102: Keep out of reach of children.

Always follow the system operating recommendations provided in the manufacturer’s instruction manual.
Intended Use: A glycol-based concentrate (propylene glycol) for heating and cooling systems (protection against freezing and corrosion).

Instructions for Use:

Dilution: Dilute with water before use (demineralized water recommended).
System Preparation: Before filling, it is recommended to drain and flush the system.
Application: Fill the system with the prepared solution and thoroughly vent it.
Control: Periodically check concentration (refractometer), pH, and fluid condition.
Operation: Replacement recommended every 3–5 years or depending on operating conditions.
Limitations: Do not use the concentrate undiluted. Do not mix with other fluids.
Storage: Store in tightly closed containers at temperatures between +5°C and +30°C.
Safety: Use in accordance with the Safety Data Sheet (SDS). Avoid contact with eyes and skin.

QR Glitherm PRO concentrate

Please send me the product’s technical documentation:

Additional information

BASE COLOR: Green.
OTHER COLORS AVAILABLE: Pink.
AVAILABLE PACKAGING: 20L Canister, 220L DRUM, IBC/DPPL 1000L, Bulk in tanker/Tank container.
PRIVATE BRAND: Possibility to apply customer labels.

Application

GLITHERM EKO Heat Transfer Fluid Concentrate can be used to prepare mixtures, working fluids used in:

Installations in the food industry without direct contact with food.
Industrial HVAC installations.
Heating installations.
Central heating installations.
Sprinkler systems.
Refrigeration and air-conditioning installations.
Ground and monoblock heat pumps.
Solar collectors.

Advantages

Concentrated formula.
It does not contain CMR (carcinogenic, mutagenic and reproductive) substances.
A product of the latest generation, its use eliminates the need for forced refrigerant replacement.
Due to the high glycol content compared to ready-to-use liquids, the concentrate takes up less space in transport and storage.
The high concentration of glycol makes it possible to prepare any standard solution or mixture with an individual composition dedicated to a given installation.
The ability to prepare the working liquid on site, just before filling the installation, allows you to order the concentrate at an earlier stage of the investment, when, for example, information on the final composition of the mixture is not yet known.
It has the ITB Technical Recommendation.
It has the Hygienic Certificate of the National Institute of Hygiene.
Protects the installation against corrosion.
Prevents the formation of deposits.
Keeps the installation clean.
It inhibits the development of microbial life.
It does not foam.
It is non-toxic and ecological.
Protects against soil and groundwater contamination.
It is safe for human life and health and the natural environment.
It does not contain glycerin and alcohol additives.
It contains only virgin raw materials, not derived from regeneration processes.
It is a multi-season agent.
Keeps the installation in good condition for years of use.
It has a 5-year manufacturer’s warranty.
It can be dyed pink.

Dilution

The manufacturer recommends diluting the concentrate with demineralized water.

To obtain specific frost resistance, you should prepare the mixture according to the table below:

Dedicated minimum temperature for a given mixture in °C	% of concentrate*	% of demineralized water*
-35°C	55	45
-30°C	52	48
-25°C	47	53
-20°C	42	58
-15°C	36	64

* Volume percentage.

If the minimum temperature at which the Heat Transfer Fluid is to work in your installation is not in the above list, the manufacturer strongly advises against setting this value yourself. The dilution of Glitherm ECO Concentrate for non-standard minimum operating temperatures should be consulted with Customer Service. The manufacturer’s technologists will carry out the appropriate calculations and present a dedicated individual solution.

Packaging and Labels

We offer GLITHERM EKO Antifreeze Concentrate in a wide range of retail and wholesale packaging. Depending on the customer’s preferences, the product can be packaged in the following packages:

20L canister – 12 pcs on half pallet, 42 pcs on a EURO pallet, 48 pcs on an industrial pallet.
220L drum – 1 pc on half pallet, 2 pcs on a EURO pallet, 4 pcs on an industrial pallet.
1000L IBC.
Bulk in a tank truck/tank container.

We can provide other packaging upon request.

It is also possible to label packages with the customer’s label or prepare a label in the language of the destination country.

The canisters are packed on a collective pallet and secured with stretch foil.
